贴片铝电解电容
| 图片 | 型号 | 库存 | 价格 | 数量 | 规格书 | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PF1A101MP20511F3UALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
1,915 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | PF | Active | 100 µF | ±20% | 10 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 139 mA @ 120 Hz | 208.5 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
EY2A4R7MP20511F6UALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
1,728 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | EY | Active | 4.7 µF | ±20% | 100 V | - | 6000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | 80 mA @ 100 kHz | 2.1 Ohms | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
MJ2W121MNN1835A4EJALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
140 | - |
立即询盘 |
规格书 |
Bulk | MJ | Active | 120 µF | ±20% | 450 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 820 mA @ 120 Hz | 1.845 A @ 100 kHz | 400 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.437 (36.50mm) | - | Through Hole |
|
|
MW2W101MNN1830A4EALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
148 | - |
立即询盘 |
规格书 |
Bulk | MW | Active | 100 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 900 mA @ 120 Hz | 1.12 A @ 100 kHz | 400 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.299 (33.00mm) | - | Through Hole |
|
CED1A221MCB6377ALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
1,000 | - |
立即询盘 |
规格书 |
Tape & Reel (TR),Cut Tape (CT) | CED | Active | 220 µF | ±20% | 10 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 112 mA @ 120 Hz | 280 mA @ 100 kHz | 340 mOhms | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EK1V471MP51016EUALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
660 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | EK | Active | 470 µF | ±20% | 35 V | - | 4000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 825 mA @ 120 Hz | 1.65 A @ 100 kHz | 30 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.689 (17.50mm) | - | Through Hole |
|
|
RF1V331MP51012EUALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
711 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | RF | Active | 330 µF | ±20% | 35 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 700 mA @ 120 Hz | 1.4 A @ 100 kHz | 39 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
|
CED1H470MCB6377F2ALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
917 | - |
立即询盘 |
规格书 |
Tape & Reel (TR),Cut Tape (CT) | CED | Active | 47 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 92.5 mA @ 120 Hz | 185 mA @ 100 kHz | 680 mOhms | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
CED1C221MCB6377ALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
690 | - |
立即询盘 |
规格书 |
Tape & Reel (TR),Cut Tape (CT) | CED | Active | 220 µF | ±20% | 16 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 112 mA @ 120 Hz | 280 mA @ 100 kHz | 340 mOhms | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
PF2F180MP51020RALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
750 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | PF | Active | 18 µF | ±20% | 315 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 200 mA @ 120 Hz | 280 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.846 (21.50mm) | - | Through Hole |
|
|
MW2G680MNN1625A4EALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
199 | - |
立即询盘 |
规格书 |
Bulk | MW | Active | 68 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 550 mA @ 120 Hz | 621.5 mA @ 100 kHz | 400 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.043 (26.50mm) | - | Through Hole |
|
|
CHJ1J221MCB12D5F2ALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
186 | - |
立即询盘 |
规格书 |
Tape & Reel (TR),Cut Tape (CT) | CHJ | Active | 220 µF | ±20% | 63 V | 250mOhm @ 120Hz | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | - | 500 mA @ 100 kHz | 250 mOhms | - | 0.492 Dia (12.50mm) | 0.571 (14.50mm) | 0.504 L x 0.504 W (12.80mm x 12.80mm) | Surface Mount |
|
|
VW2W680MNN1626AESALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
196 | - |
立即询盘 |
规格书 |
Bulk | VW | Active | 68 µF | ±20% | 450 V | 900mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 700 mA @ 120 Hz | 1.05 A @ 100 kHz | 500 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.083 (27.50mm) | - | Through Hole |
|
|
VW2W101MNN1825A4EF3ALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
3,789 | - |
立即询盘 |
规格书 |
Bulk | VW | Active | 100 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 900 mA @ 120 Hz | 1.35 A @ 100 kHz | 300 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.043 (26.50mm) | - | Through Hole |
|
|
EG1H4R7MP20511EUALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
2,244 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | EG | Active | 4.7 µF | ±20% | 50 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | 70 mA @ 100 kHz | 1.5 Ohms | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
SM1E101MPN6311UALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
2,408 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | SM | Active | 100 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 190 mA @ 120 Hz | 285 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EY1H4R7MP20511EUALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
3,307 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | EY | Active | 4.7 µF | ±20% | 50 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | 120 mA @ 100 kHz | 1.5 Ohms | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
ED1H4R7MP20511RUALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
3,310 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | ED | Active | 4.7 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | 135 mA @ 100 kHz | 1.02 Ohms | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EY1H100MP20511UALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
2,630 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | EY | Active | 10 µF | ±20% | 50 V | 13.3Ohm @ 120Hz | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 40.5 mA @ 120 Hz | 135 mA @ 100 kHz | 1.3 Ohms | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EV1H4R7MP20511EF4UALUMINUM ELECTROLYTIC CAPACITORS Chinsan (Elite) |
3,219 | - |
立即询盘 |
规格书 |
Cut Tape (CT),Tape & Box (TB) | EV | Active | 4.7 µF | ±20% | 50 V | - | 4000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | 140 mA @ 100 kHz | 1.344 Ohms | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
